MANHATTAN kabel Mini DisplayPort, Male to Male, 1m, White

Specifikace kabelu / redukce:Mini Display Port.... více
Běžná cena: 148  (-16%)
103.31 Kč bez DPH
Skladem > 5 ks
125 Kč
ks
Vyberte si zvýhodněné balení
Množstevní slevy
Kód: 254051
Kód dod.: 324557
EAN: 766623324557
Záruka: 2 Rok(ů)
Výrobce: Manhattan
Popis a parametry

MANHATTAN kabel Mini DisplayPort, Male to Male, 1m, White

High-definition performance for personal computing.

Manhattan Mini DisplayPort cables deliver both high-definition digital audio and video signals between desktop or notebook computers and an output device. The 20-pin connector is small and compact but offers 14.8 Gbps bandwidth, Deep Color and 24-bit, 8-channel uncompressed audio capability. It's ideal for use with DisplayPort-equipped computers, flat-panel displays, slim-profile devices and many consumer electronics including Blu-ray players and game consoles. Full foil and braided shielding, molded boots with strain relief, protective PVC jackets and gold-plated connections ensure that Manhattan DisplayPort Cables provide maximum conductivity and clear, crisp signal transmissions with reduced EMI interference and distortion.


Features:



  • Mini DisplayPort 20-pin male to Mini DisplayPort 20-pin male with strain relief boots

  • Delivers high-bandwidth, bi-directional, 14.8 Gbps, digital audio/visual signals from source to display — up to 4Kx2K@60Hz

  • 4K, UHD resolution supports video resolution four times 1080p; up to 1080p resolution in 3D and Deep Color

  • Dolby and DTS-HD 2/5.1/7.1/8 uncompressed surround sound audio pass-through

  • Fully shielded to reduce EMI and other interference sources

  • Supports the HDCP and DPCP content protection standards

  • Lifetime Warranty



Specifications:


Standards and Certifications



  • UL 20276

  • DisplayPort 1.2

  • ISO 9002

    General

  • Bandwidth: 14.8 Gbps at 600 MHz

  • Meets or exceeds existing DisplayPort standards

  • Length: 1 m

    Connectors

  • Mini DisplayPort 20-pin male (2)

  • Gold plated

  • Gold-plated contacts

  • ABS boots, built-in ABS strain relief

    Cable

  • 32 AWG

  • Shielding: aluminum and Mylar braid

  • Withstanding voltage: 300 VDC

  • Insulation resistance: 5 M?

  • Contact resistance: 10 Ohms

  • Current rating: 0.5 A DC

  • Conductive resistance: 5 Ohms

  • Thermal plastic casing

    Operating Environment

  • Operation Temperature: 0 - 50°C (32 - 122°F)

  • Storage Temperature: -25 - 85°C (-13 - 185°F)

  • Humidity (noncondensing): 0 - 96%

    Package Contents

  • Mini DisplayPort Cable

.
Specifikace kabelu / redukce
Mini Display Port
