Inspired from architectural design with the extended heatsink for having better thermal solution; high speed USB 3.2 Gen2x2 solution, Core Boost, DDR4 Boost, 10G LAN card, Dual LAN onboard, Twin Turbo M.2 with M.2 Shield Frozr, M.2 Xpnader-Z
Supports Intel® Core™ X-series Processors 10000/9000/78xx(above)series for LGA2066 Socket
Supports DDR4 Memory, up to 4200+(OC) MHz
Lightning USB 20G: Powered by ASMedia ASM3242 USB 3.2 Gen2x2 controller, offers the fastest USB speeds with stability.
Twin Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.
M.2 XPANDER-Z: Offers two extra M.2 slots to increase your storage capacity at maximum speed.
Set Core Power Free: Core Boost, 2x8 pin CPU power connector, Core Boost, DDR4 Boost.
Extended Heatsink Design: MSI extended PWM and enhanced circuit design ensures even high-end processors to run in full speed.
Dual LAN onboard: Premium network solution included 1x 2.5G LAN for professional and multimedia use. Delivers a secure, stable and fast network connection.
10G Super LAN card: Next level network speed, secure networking with fastest data throughput to improve efficiency.
Audio Boost 4: Reward your ears with studio grade sound quality.
For the latest information about memory, please visit http:/
4x PCIe 3.0 x16 slots
Support x16/x8/x16/x8 mode with the 48-lane CPU.1
Support x16/x4/x16/x8 mode with the 44-lane CPU.1
Support x16/x4/x8/x0 mode with the 28-lane CPU.1 Please refer to user manual for PCIe 3.0 bandwidth table.
Supports 3-Way NVIDIA® SLI™ Technology
Supports 3-Way AMD® CrossFire™ Technology
Intel® X299 Chipset
6 x SATA 6Gb/s ports1
2 x M.2 slot (Key M)
Support up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices2,3
Intel® Optane™ Memory Ready4
The SATA1 connector will be unavailable when a SATA M.2 SSD has been installed in the M2_1 slot.The M2_2 default setting is CPU lane. However, when a PCIe expansion card is installed in the PCI_E2 slot, the M2_2 will be automatically switched to PCH lane.The SATA2 connector will be unavailable when M2_2 uses PCH lanes and a M.2 SATA SSD is installed in the M2_2 slot.M2_2 supports Intel® Optane™ Memory by switching to PCH lanes.
Intel® X299 Chipset
Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 PCIe storage devices
ASMedia® ASM3242 Chipset 1 x USB 3.2 Gen2x2 (SuperSpeed USB 20Gbps) Type-C port on the back panel
ASMedia® ASM3142 Chipset 1 x USB 3.2 Gen2 (SuperSpeed USB 10Gbps) Type-C internal connector
Intel® X299 Chipset 8 x USB 3.2 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 4 ports available through the internal USB connectors) 8 x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 4 ports available through the internal USB connectors)
Realtek® ALC1220 Codec 7.1-Channel High Definition Audio Supports S/PDIF output
1 x Intel I219-V Gigabit LAN controller1
1 x Realtek RTL8125-CG 2.5G LAN controller
1 x Aquantia® AQC107 10-Gigabit LAN card I219 LAN doesn’t support G3 to S5 Wake
1 x 24-pin ATX main power connector
2x 8-pin ATX 12V power connectors
6x SATA 6Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
2x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports)
