GIGABYTE BRIX GB-BLCE-4105C, Intel J4105, 1xSODIMM DDR4, VGA
Popis a parametry
GIGABYTE BRIX GB-BLCE-4105C, Intel J4105, 1xSODIMM DDR4, VGA
GB-BLCE-4105 C(rev. 1.0)
Ultra Compact PC kit
Features
- Features Intel® Celeron® Processor J4105
- Ultra compact PC design at only 0.67L (56.22 x 103 x 116.52mm)
- 1 x SO-DIMM DDR4 slot
- Intel® IEEE 802.11ac, Dual Band Wi-Fi & Bluetooth 4.2 NGFF M.2 card
- HDMI plus D-Sub Outputs (Supports dual displays)
- 4 x USB 3.0 (1* USB Type-C™)
- Gigabit LAN
- Headphone and Microphone Jack
- VESA Mounting Bracket (75 x 75mm + 100 x 100mm)
* Wireless module inclusion may vary based on local distribution.
TECHNICAL SPECIFICATIONS
| Dimension | 56.22 x 103 x 116.52 mm (2.21" x 4.06" x 4.59") |
| Motherboard Size | 104 x 103 mm |
| CPU | Intel® Celeron® Processor J4105 2.5GHz, 4 core (TDP 10W) |
| Memory | 1 x SO-DIMM DDR4 slot 2400MHz Max. 8GB |
| LAN | Gigabit LAN (Realtek RTL8111HS) |
| Wifi Card | Intel® Dual Band Wireless-AC 3168 |
| Graphics | Intel® UHD Graphics 600 |
| Audio | Realtek ALC891 |
| VGA Resolution (Max.) | 1920 x 1200 @60 Hz |
| HDMI Resolution (Max.) | HDMI1.4b 1920 x 1080 @ 60 Hz |
| Expansion Slots | 1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the WiFi+BT card |
| Front I/O | 1 x Power Button 1 x USB3.0 1 x USB3.0 type-C 1 x Headphone Jack 1 x Microphone Jack |
| Rear I/O | 1 x HDMI(1.4b) 2 x USB 3.0 1 x RJ45 1 x VGA |
| Side I/O | 1 x Kensington lock slot |
| Storage | Supports 2.5" HDD/SSD, 7.0/9.5 mm thick (1 x 6 Gbps SATA 3) |
| Power Supply | Input: AC 100-240V Output: DC 19V 2.1A |
| VESA | Bracket included Supports 75 x 75 and 100 x 100 mm |
| Environment | System Environment Operating Temperature: 0°C to +35°C System Storage Temperature: -20°C to +60°C |
| Support OS | WIN10 64bit |
.
ParametryPřidat do porovnání
Řada procesoru
Intel Celeron
Druh optické mechaniky
Bez optické mechaniky
Operační systém
Bez OS
Kapacita paměti grafické karty (v MB)
Nespecifikováno
Grafický čip
Intel HD
Provedení PC
Mini-PC
Využití PC
Domácnost a kancelář
Rozhraní
3.5mm Jack
